CP Method:	Rocksim/Rocksim
CP Position From Front:	18.25 inches
Diameter:	1.64 inches
Fin Material:	Balsa
Length:	24.00 inches
Manufacturer:	Estes
Model:	6
Motor Size:	18 millimeters
Nose Cone Material:	Balsa
Original Price:	$2.75
Power:	Low-Power
Product Type:	Kit
Production Years:	1962-1971
Recommended Motors:	3xA8-3, 3xB6-4, 3xC6-5
Recovery:	Parachute
Status:	Out-Of-Production
Weight:	3.40 ounces

Reviews

• Estes Ranger By Ray King

  Brief: Modified Estes Ranger - a three motor cluster rocket with a payload section. My version includes a baffle and uses motor hooks that were not part of the original kit. I was looking for a kit or a plan that would be suitable to fulfill the NARTREK Silver cluster flight requirements. This look alike to the Big Bertha would be a great addition to my fleet if painted in a similar scheme ...
