Designs >> Rocksim Library >>	All Rocksim Designs (1688 of 3219)Tag - Manufacturer:LOC/Precision

Caliber ISP Rocksim Design File

Contributed by Cliff Sojourner

• Manufacturer: LOC/Precision

Comments: your basic 3.1" x 60" 4FNC 54mm blaster

Designer: LOC Precision

Download loc_caliber_isp.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: LOC/Precision - Caliber ISP

CG: 29.7193 inches from front
CP: 48.7874 inches from front
Margin: 6.15 Overstable

Parts Breakdown

• BSD Canadian Sprint 38mm Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 14.00 in]
• LOC Precision TC-3.00 Ring
• Custom Ring
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 34.00 in]
• LOC/Precision Rip stop nylon Parachute (36.00 in)
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 10.00 in]
• LOC Precision LOC CR-3.00-2.14 Ring
• LOC Precision LOC CR-3.00-2.14 Ring
• Caliber ISP Trapezoid Fin Set Trapezoid Fin Set
