Guardian Rocksim Design File

Contributed by Joe Policy

• Manufacturer: Estes
• Recovery: Parachute
• Style: Sport

Designer: Estes

Download estes_guardian.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Guardian {Kit} (2179) [2003-2014]
Diameter: 1.3300 inches
Length: 19.1300 inches
Style: Sport

CG: 10.5150 inches from front
CP: 15.6772 inches from front
Margin: 5.29 Overstable

Parts Breakdown

• Guardian Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]
• Guardian Trapezoid Fin Set Trapezoid Fin Set
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.25 in]
• Estes 30125 Ring
• Estes 30125 Ring
• Guardian Freeform Fin Set Freeform Fin Set
• Guardian Freeform Fin Set Freeform Fin Set
• Estes ESTES 2321 Launch Lug
• Estes Polyethylene LDPE Parachute (12.00 in)
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.76 in]
• Quest 14000 Ring
• Estes Eng. Hook Sleeve Ring
• Estes Engine hook Standard size Mass Object
