SDI Satellite Rocksim Design File

• Manufacturer: Estes

Comments: tube fins per Bruce Levinson's method but modified in thickness to approximate frontal area of the plugged tubes; simulated the 2 solar panels with 4 fins of equivalent area

Designer: Estes

Download oop_estes_sdi_satellite.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - SDI Satellite {Kit} (2003) [1989-1992]

CG: 7.4893 inches from front
CP: 9.0294 inches from front
Margin: 4.53 Overstable

Parts Breakdown

• Estes SDI Satellite Power Series Nose Cone
• Custom Conical Transition
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.69 in]
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.19 in]
• Custom Conical Transition
• Custom Conical Transition
• Custom Conical Transition
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.37 in]
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.50 in]
• Estes Polyethylene LDPE Parachute (12.00 in)
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Estes SDI Satellite Trapezoid Fi Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.50 in]
• Estes 30125 Ring
• Estes 30125 Ring
